Large Volume Centrifugal Medium Pressure Fans
CFM
Up to 360,000 m³/h (6,000 m³/min) and 17,500 Pa. With direct, coupling or belt drive - frequency converter operation also possible. Housing and impellers with blades bent backwards and made of steel or stainless steel. Variable connection possibilities. Fans of this type series are always configured specific to the project.
Characteristic curves
Performance data
Efficiency class
Volume flow
Total pressure difference
Voltage
Frequency
Performance
Weight
-
m³/h
Pa
V
Hz
kW
kg
CFM
IE1/IE2/IE3/NEMA
0
0
230/400, 277/480, 400, 480
50/60
0,75
100
